G25371 - Tiny Micro-Motor 6mm dia. x 12.2mm long 1.5V up to 3VDC

G25371 - Tiny Micro-Motor 6mm dia. x 12.2mm long 1.5V up to 3VDC

item number: G25371
unit price:$1.49

Detailed Description

Tiny micro-motor is only 6mm dia. x 12.2mm long. Operates on 1.5VDC up to 3VDC. At 3VDC the RPM is 34,000. The shaft of this motor is 0.8mm dia. x 3.7mm long. Power connection is made between tab at back of motor and case. There are no leads attached, but it's very simple to connect power to this motor. It comes with a removable mounting clip that you just push the motor into. Just solder one lead to tab on back of motor and solder another lead to the clip. Brand New.
